DeVore Fidelity O/Reference Loudspeakers

The O/Reference is the flagship of DeVore Fidelity's Orangutan series, developed over roughly a decade of exploring the design's performance limits rather than market demand.

It splits the lowest octave into a separate bass module so the main two-way cabinet can stay simple and easy to drive, with the module's passive radiator naturally tuned below 20Hz rather than extended with equalization, for a seamless blend with the main cabinets.

The 10-inch paper-cone woofer uses an Alnico magnet motor with copper Faraday rings and a titanium former, and the tweeter and supertweeter are horn-loaded through cast bronze horns; the bronze and brass parts are decoupled from the cabinet to reduce vibration.

It is offered in a 4-piece configuration with dual bass modules or the 3-piece O/Reference 3 with a single, mono-summed bass module. Confirm which configuration a quote covers, since the two carry different pricing. Finish flexibility is broad; confirm the current veneer/decor list with DeVore before finalizing a customer order.

Specifications

• Drivers (O/Ref A, main cabinet): 10-inch paper-cone woofer on a cast-bronze chassis with Alnico motor; 1-inch silk-dome tweeter with bronze horn; 0.75-inch silk-dome supertweeter with bronze horn
• Drivers (O/Ref B, bass module): 11-inch reinforced-aluminum woofer plus 11-inch aluminum passive radiator, built-in 700W Class D amplifier
• Frequency response: 15Hz-50kHz
• Sensitivity: 98dB/W/m
• Impedance: 12 ohms
• Amplification: bass module self-powered (700W Class D); main cabinets pair with an external amplifier
• Cabinet: 4-piece system (or 3-piece O/Ref 3 configuration); 2-inch birch-ply front baffle on the bass module; horn-loaded bronze tweeter and supertweeter
• Dimensions: 18 in W x 35.5 in H x 12 in D per main cabinet, with stands
• Finish: flexible custom decor/finish program; confirm current options with DeVore
